Brand: YZ Automatic packing machine
Description: A series of YZ (automatic horizontal packing machine) especially suits the requirements of high efficient user. The machine specially used for packaging paper, cardboard, plastic film, carton and palm silk etc.. This series of machines can be under the control of PLC system automatic feeding, packaging, bundling. Scope of application: Carton plant and waste paper, waste paper processing. 1, automatic waste paper baler for environmental protection requirements, designed for paperboard, cartons and recycled materials recycling companies manufacturing professional design. The 2 locking design, can be allocated from the direction of the pressure. The 3.PLC control system, simple operation. The 4 storage box is provided with a paper feeding sensing infrared, the motor stops automatically adds no material, saving power. 5 baling length and density can be adjusted freely, packing speed, simple structure. 6 design easy to repair, low failure rate and easy cleaning and maintenance. The 7 independent computer full touch screen control panel, easy and convenient operation. Twisted pair and gearbox independent design, to prevent oil pollution damage, and easy cleaning wire threading system repair tool is simple, long mechanical life, unique mechanical design, the threading action accurate.
Specifications
Model YL-120T
Voltage 200V/380V/415V
The motor power of 45 KW
Automatic operation mode
Block size L (free) *W920*H920 mm
Cylinder size φ 270 m
Blanking size L1860*W900 mm
The maximum working pressure of 1200 KN
Working pressure of 17 MPa
The noise of 80 dB
Fuel tank capacity of 1100 L
Packing line number 4
Mass density 520-550 kg/m ³
Packaging capacity of 8-9 tons / hour
Machine weight 25000 kg
Size of the machine L8700*W12200*H4120 mm
